PCD Tipped Circular Saw Blade for Fiber Cement Board
Our fiber cement saw blades are designed for maximum durability and precision cutting. Made with premium polycrystalline diamond (PCD) tips, they offer extended lifespan and superior cutting performance on fiberboard, cement board, and composite materials.
Saw blades for cutting fiber cement board
Technical specifications:
Diameter: 184mm(7.25″)
Arbor: 15.88mm
Grind: P
Hook Angle:
Kerf: 1.9
Plate: 1.2
Teeth: 6T
Discount: There is cartain discount if quantity 100 pieces or above
Description
Product Overview
PCD section, German imported steel plate 75CR1, and Japanese imported steel plate SKS51 are the raw materials.
Features
● 1. Application on cutting fiberboard, also supplying other kinds saw blades for cutting aluminium materials, melamine board, MDF.
● 2. Applied on kinds of machines table saw, portable saw.
Height light:
● 1. PCD segment promised a longer tools life and enable the blades to last longer,maximizing cutting life and material finish in a variety of materials.
● 2. Anti-Vibration design reduces vibration and promote in excellent performance.
● 3. Strict procedures to make sure the saw blades in high quality,increasing efficiency,save time with competitive price and lower tooling price.
● 4. Using Gerling machines to finish teeth brazing process and sandwich silver-copper-silver technology to make the strength of teeth.
Technical:
1. Strictly regulate the temperature when brazing the PCD section.
2. Finish the grinding process with a copper electrode sanding wheel, which is the most crucial technique for PCD saw blades.
3. The standard length of a PCD tooth is 6.0mm, however it may be adjusted to meet special needs, such as 6.8mm and 7mm. The longer the section, the longer the working life.
PCD saw blades are significantly more expensive than carbide saw blades. It is projected to be 50 times more expensive than a TCT carbide-tipped saw blade. For example, you may pay 5 times more for a product that lasts 50 times longer and can run the machine for 30 days without replacing the blades.
Parameters
▲1.Saw blades for fiberboard:
Diameter: 127mm-400mm
Number of teeth: 4T-96T
Kerf thickness: 1.9mm, 2.2mm, 4.0mm
▲2.Saw blades for fiberboard often have fewer teeth than other types of blades. The specific number of teeth is not provided.
▲3.Below are some basic PCD saw blade specifications for fiberboard saw blades with quick delivery. You welcome bespoke orders, which means that you can produce saw blades according to the customer’s specific requirements or specifications.
| OD(mm) | Bore | Kerf Thickness | Plate Thickness | Number of Teeth | Grind |
| 127 | 15.88 | 1.9 | 1.2 | 6 | P |
| 184 | 15.88 | 1.9 | 1.2 | 4 | P |
| 184 | 15.88 | 1.9 | 1.2 | 6 | P |
| 256 | 15.88 | 2.2 | 1.5 | 6 | P |
| 305 | 25.4 | 2.2 | 1.5 | 8 | P |
| 305 | 30 | 2.8 | 2.2 | 12 | P |
| 350 | 60 | 4 | 3.5 | 48 | P |
| 380 | 60 | 4 | 3.5 | 60 | P |
| 380 | 60 | 4 | 3.5 | 96 | P |
| 400 | 60 | 4 | 3.5 | 96 | P |
Applicatons
- Fiber Cement Board Cutting – Ideal for cutting fiber cement siding, cement backer board, and composite cement panels with minimal chipping and dust.
- Fiberboard Processing – Perfect for cutting MDF (Medium-Density Fiberboard), HDF (High-Density Fiberboard), and particleboard in furniture and cabinetry production.
- Laminate & Veneer Panels – Provides clean cuts on melamine, laminated plywood, and veneer-covered boards without tear-out.
- Composite Material Cutting – Used in industries working with plastic composites, solid surfaces, and engineered wood products.
- Construction & Prefabrication – Essential for builders and contractors needing precise and efficient cuts in fiber-cement materials for siding, flooring, and wall panels.
